6mm Plate bending machine,6mm Sheet metal bending machine for sale
Description:
The W11-6X2500 plate rolling machine is three-roller symmetric structure; driven by screw lever and turbine worm, the upper roller moves in vertical direction in the center symmetrical position between the lower two rollers; As the main drive roller for rotary motion, two lower rollers are engaged with the output gear of the reducer to provide torque for rolling plate. The machine is compact, easy operation and maintenance; besides, the roller is suitable for installation of profile dies for easy rolling of various profiles.
Standard configuration:
●Easy-to-use removable console
●The upper roller is electrically depressed through the console
●Suitable for thin and heavy plate, aluminum or stainless steel sheet rolling
●Ferrules in full circle or varying radiuses can be done easily
●Overload protection
●Two sets of digital output for easy positioning of two lower rollers
●Extended roller shafts for profile and pipe rolling operation
Technical parameter:
| Name | Configuration Parameter | W11-6/2500 | |
| Max Plate Thickness | <450N/mm2 | mm | 6 |
| <700N/mm2 | mm | 4 | |
| Max Plate Length | ( A ) | mm | 2500 |
| Loaded with minimum volume plate diameter | Mm | 380 | |
| Yield Limit | N/mm2 | 245 | |
| Rolling Speed | m/min | 4.5 | |
| Upper Roller Diameter | mm | 180 | |
| Lower Roller Diameter | mm | 170 | |
| Lower Roller Center Distance | mm | 260 | |
| Main Motor Power | kw | 5.5 | |
| Length | ( A ) | mm | 4300 |
| Width | ( B) | mm | 910 |
| Length | ( H ) | mm | 1150 |
| Weight | kg | 2600 | |
