8mm Sheet metal rolling machine,bending 8mm Thickness Sheet metal roller for sale
Description:
W11 8×2500 sheet metal rolling machine is three-roller symmetrical structure; the upper roller is driven by the lead screw and the worm gear to move in the vertical direction at the center symmetrical position between the lower two rollers. As the main driving roller for rotating motion, the two lower rollers mesh with the output gear of the reducer to provide torque for the rolling plate. The machine has a compact structure and is easy to operate and maintain; in addition, the roller is also suitable for installing profile molds to facilitate rolling of various profiles.
Standard configuration:
●Easy-to-use removable console
●The upper roller is electrically depressed through the console
●Suitable for thin and heavy plate, aluminum or stainless steel sheet rolling
●Ferrules in full circle or varying radiuses can be done easily
● Overload protection
●Two sets of digital output for easy positioning of two lower rollers
●Extended roller shafts for profile and pipe rolling operation
Technical parameters:
| Name | Configuration Parameter | W11-8/2500 | |
| Max Plate Thickness | <450N/mm2 | mm | 8 |
| <700N/mm2 | mm | 5 | |
| Max Plate Length | ( A ) | mm | 2500 |
| Loaded with minimum volume plate diameter | Mm | 550 | |
| Yield Limit | N/mm2 | 245 | |
| Rolling Speed | m/min | 4.5 | |
| Upper Roller Diameter | mm | 240 | |
| Lower Roller Diameter | mm | 180 | |
| Lower Roller Center Distance | mm | 280 | |
| Main Motor Power | kw | 7.5 | |
| Length | ( A ) | mm | 4300 |
| Width | ( B) | mm | 910 |
| Length | ( H ) | mm | 1250 |
| Weight | kg | 4000 | |
