8mm thickness Plate rolling machine for sale,2 meter Sheet metal roller

8mm thickness Plate rolling machine for sale,2 meter Sheet metal roller

Description

W11 8×2000 plate rolling machine is three-roller symmetrical structure; the upper roller is driven by the lead screw and the worm gear to move in the vertical direction at the center symmetrical position between the lower two rollers. As the main driving roller for rotating motion, the two lower rollers mesh with the output gear of the reducer to provide torque for the rolling plate. The machine has a compact structure and is easy to operate and maintain; in addition, the roller is also suitable for installing profile molds to facilitate rolling of various profiles.

Features

1.European standard design

2.Three-roller symmetric structure, compact, easy operation and maintenance

3.Easy-to-use removable console

4.Two sets of digital output for easy positioning of two lower rollers

5.SAE 1050 quality certificate

Standard configuration

●Easy-to-use removable console

●The upper roller is electrically depressed through the console

●Suitable for thin and heavy plate, aluminum or stainless steel sheet rolling

●Ferrules in full circle or varying radiuses can be done easily

●Overload protection

●Two sets of digital output for easy positioning of two lower rollers

●Extended roller shafts for profile and pipe rolling operation

Safety standard

●Safety standards (2006/42 / EC)

●Open the electrical cabinet door to power off

●Domestic pedal switch ( safety grade 4 )

●Body metal safety rail conforms to CE standards

●Safety relay monitors the pedal switch, safety protection

Technical parameters
